            Optional Features

            Column

            Makeup Reservoir


            You can use these reservoirs with any spring return shock absorber, specifically those used in higher cycle applications, to automatically replenish oil lost during normal operation. Use the .25oz design with 3/4" Series A model and the standard 2.5oz with any Series S model and the Series A 1-1/8", 1-1/2", and 2" models.

            Column


            Safety Chains


            These chains are recommended with any shocks used with crane operation. They meet the OSHA and AISE specifications.

            Column

            Internal Stop


            Used for extremely dirty operating conditions where dirt and grit is liable to be pounded into the gland retainer by the bumper. Add the RR dimension found in the catalog to accommodate for the extra length. Internal stops are standard in the Heavy Duty Series H models and the 3/4" and 2" bore Adjustable Series A models.

            Click to edit


            High Temperature Operation


            A special viton/silicone seal package and a high temperature fluid is recommended if your shock is going to see an above average cycle rate or is operating in a high temperature environment.


            Specialty Features

            We offer custom features such as a specific mounting, fractional stroke length, or intermediate stops, as well as special finishes such as Nitrotec, stainless steel, or zinc-nickel plating. Whatever you need, we look forward to working with you to give you the most efficient shock.
